One thing that I’ve struggled with since adopting NixOS over a year ago was somehow integrating my virtual machine infrastructure into my NixOS deployments. I wanted to be able to define the virtual machine infrastructure in Nix code exactly how you would define a NixOS system in Nix code too so when you would rebuild the NixOS system it would also create/update any virtual machine infrastructure as well.
In researching how this could be achieved I came across a few existing soltuions.
While the aforementioned solutions are mature and battle-tested they did not work for my circumstances. Instead I opted to create a solution that utilized Terraform technology combined with Nix.
Preparing the host/hypervisor
Installing virtualisation packages
The first thing I needed to do is install the KVM/QEMU/Libvirt stack on a machine that will run the virtualisation infrastructure. Using Nix this can be achieved by including the following code in our system configuration.
# configuration.nix
{ pkgs, ... }:
{
virtualisation.libvirtd = {
enable = true;
onBoot = "start";
onShutdown = "shutdown";
qemu.ovmf.enable = true;
};
environment.sessionVariables = {
LIBVIRT_DEFAULT_URI = "qemu:///system";
};
environment.systemPackages = with pkgs; [
libxslt
opentofu
virt-manager
];
# rest of system configuration code...
}Setting up networking
Next I wanted to have my virtual machines appear as their own standalone hosts on my private subnet (no host-to-vm NAT) which means I needed to turn one of my physical nterfaces on the hypervisor into a bridge. Since my hypervisor was just a refurbished desktop I only had one NIC available to me so management and VM traffic would be on the same interface. Ideally this would be seperated but for a home-lab environment this will have to suffice.
# configuration.nix
{ pkgs, lib, ... }:
{
networking = {
networkmanager.enable = lib.mkForce false;
domain = "megacorp.industries"; # <--- Change this
useDHCP = false;
useNetworkd = true;
};
services.resolved = {
llmnr = "false";
};
systemd.network = {
enable = true;
netdevs.br0 = {
enable = true;
netdevConfig = {
Kind = "bridge";
Name = "br0";
};
};
networks = {
br0-lan = {
enable = true;
matchConfig = {
Name = ["br0"];
};
networkConfig = {
Bridge = "br0";
};
};
br0-lan-bridge = {
enable = true;
matchConfig = {
Name = "br0";
};
networkConfig = {
DHCP = "no";
Address = "192.168.1.15/24"; # <--- Change this
DNS = ["192.168.1.45"]; # <--- Change this
Domains = "megacorp.industries"; # <--- Change this
};
routes = [
{
Destination = "0.0.0.0/0";
Gateway = "192.168.1.99"; # <--- Change this
}
];
};
enp6s0 = {
matchConfig = {
Name = "enp6s0"; # <--- Change this
};
networkConfig = {
Bridge = "br0";
DHCP = "no";
DNS = ["192.168.1.45"]; # <--- Change this
Domains = "megacorp.industries"; # <--- Change this
};
};
};
};
}The above configuration disables DHCP and NetworkManager and uses systemd networking to create a bridge interface “br0” and enslave my physical interface “enp6s0” to it. If adopting this configuration be sure to change the IP and DNS info accordingly as indicated by the comments.
I also had to disable LLMNR due to local name resolution bugs.
Note: If connected to the hypervisor over SSH you will temporarily lose connectivity since you’re changing the interface you’re currently connected to.
Creating Terraform config in Nix
The next step is to somehow describe the libvirt infrastructure in code in a way that will be tied together with the NixOS hypervisor system configuration. I managed to get this working in 2 steps.
Firstly I was able to use Duncan Mac-Vicar’s terraform libvirt module to declaratively describe libvirt infrastructure using Terraform code.
Secondly I utilizied the Nix project Terranix which provides the ability to write Terraform code in Nix.
Combining these 2x technologies (with a little systemd magic) enables the ability to declare libvirt infrastructure in my NixOS system configuration and have the infrastructure update (if there are any changes) with system rebuilds.
Since I’m using flakes I only need to add the Terranix repo to my inputs…
# flake.nix
{
inputs = {
nixpkgs = "github:nixos/nixpkgs/nixos-24.11";
terranix = {
url = "github:terranix/terranix";
inputs.nixpkgs.follows = "nixpkgs";
};
};
}I then add it as a function argument to my flakes outputs and add it to specialArgs as well as my system architecture variable…
# flake.nix
{
outputs = { self, nixpkgs, terranix, ... }: let
system = "x86_64-linux";
in {
nixosConfigurations = nixpkgs.lib.nixosSystem {
specialArgs = {
inherit terranix system;
};
modules = [
./configuration.nix
];
};
};
}And pass the Terranix module + system variable to my machines configuration file as function arguments…
# configuration.nix
{ pkgs, terranix, system, ... }:
{
}Now that Terranix is ready to use in the system configuration I can begin implementing the logic. We need to ensure that when I rebuild the NixOS system any changes made to our Terraform (Terranix) code also update when NixOS is rebuilt.
First I’ll define the Terranix code in a “let in” block.
Note: I’m using a modified version of this terraform module which abstracts much of the options in the libvirt terraform provider but you can also easily substitute my terraform module decleration with the options in the aforementioned provider.
# configuration.nix
{ pkgs, terranix, system, ... }: let
terraformConfiguration = terranix.lib.terranixConfiguration {
inherit system;
modules = [
{
terraform.required_providers.libvirt.source = "dmacvicar/libvirt";
provider.libvirt.uri = "qemu:///system";
module = {
testvm = {
source = "https://github.com/rapture-mc/terraform-libvirt-module";
vm_hostname_prefix = "testvm";
uefi_enabled = false;
autostart = true;
vm_count = 1;
memory = "2048";
vcpu = 1;
system_volume = 100;
bridge = "br0";
dhcp = true;
};
};
}
];
};
in {
}Then add the systemd service which will create a directory to store out infrastructure state at /terraform-state and run “opentofu init && opentofu apply -auto-approve” whenever there’s a change in our terranix code.
# configuration.nix
{ pkgs, terranix, system, ... }: let
terraformConfiguration = terranix.lib.terranixConfiguration {
inherit system;
modules = [
{
terraform.required_providers.libvirt.source = "dmacvicar/libvirt";
provider.libvirt.uri = "qemu:///system";
module = {
testvm = {
source = "https://github.com/rapture-mc/terraform-libvirt-module";
vm_hostname_prefix = "testvm";
uefi_enabled = false;
autostart = true;
vm_count = 1;
memory = "2048";
vcpu = 1;
system_volume = 100;
bridge = "br0";
dhcp = true;
};
};
}
];
};
in {
systemd.services.libvirt-infra = {
wantedBy = ["multi-user.target"];
after = ["network.target"];
path = [pkgs.git];
serviceConfig.ExecStart = toString (pkgs.writers.writeBash "generate-terranix-config" ''
if [ -d /terraform-state ]; then
echo "/terraform-state directory exists... Skipping creating dir"
else
echo "/terraform-state directory doesn't exist... Creating dir"
mkdir /terraform-state
fi
cd /terraform-state
if [[ -e config.tf.json ]]; then
rm -f config.tf.json;
fi
cp ${terraformConfiguration} config.tf.json \
&& ${pkgs.opentofu}/bin/tofu init \
&& ${pkgs.opentofu}/bin/tofu apply -auto-approve
'');
};
}As of 2025-05-14 I haven’t been able to get UEFI working in the virtual machine. Whenever I try to reference the OVMF code file at “/run/libvirt/nix-ovmf/OVMF_CODE.fd” I get the following error:
Error: error creating libvirt domain: operation failed: unable to find any master var store for loader: /run/libvirt/nix-ovmf/OVMF_CODE.fd
Despite the file “/run/libvirt/nix-ovmf/OVMF_CODE.fd” existing on the hypervisor. Strangely enough I am able to reference that OVMF file when manually creating a libvirt machine using virt-manager.
